ALIX 1 board

Price

All prices are in AUD and include GST.

Options

Base price: $300.00

Limited stock

Availability

Information

Product Code
Category
Includes
Notes
  • In order to comply with Australian emissions regulations you will need to enclose this board in a metal case

Completely fanless, quiet and cool, the ALIX 1 is ideal for use as a thin client, in kiosks, as an industrial user interface, and in wireless routers and other special purpose network devices.

The extra power and memory of the ALIX 1 means that it’s capable of running graphical environments, including Linux, BSD and Windows XP.

The ALIX 1 board is ready for you to add your choice of Mini ITX case, storage options, power supply and expansion cards.

Performance

500 MHz AMD Geode LX800 CPU, 256 MB RAM

Storage

Compact Flash card or Microdrive and 2.5" HDD

Power

12V DC external power supply (2.5mm internal). Uses about 5W at 12V DC (excluding miniPCI cards).

Interface

GPIO, battery-backed real-time clock (RTC), buzzer

Connectivity

1 ethernet channel (10/100 Via VT6105M, supports 802.1 VLAN tagging), 1 miniPCI slot, 1 PCI slot, 2 serial (RS232) ports (console/on-board), 1 VGA port, keyboard and mouse ports, audio out and microphone ports, 2.5" IDE connector, 4 USB (2 ports/2 headers), LPT header

Size

170W x 170L (mm) (Mini ITX form factor)

Weight

250g

Manufacturer

PC Engines

Model

ALIX.1D

Compliance

C-tick labelled for use in Australia; RoHS compliant (lead-free);
